Cylindrische zekering 14x51mm 690Vac 1A aM
Artikelnr:
PV141AaM
€ 3,21
excl. BTW
(
€ 3,88
Incl. BTW
)
excl. BTW
(
Incl. BTW
)
(
Incl. BTW
)
Omschrijving
- Small dimensions.
- High limiting and breaking capacity.
- Low power losses.
- The fuse-links do not contain harmful substances according to the RoHS Regulation (cadmium, lead and other).
- Utilization category aM for protection of motors, overcurrent relays, contactors and similar devices only against short-circuit.
- Nominale spanning : 500 ÷ 690 V a.c.
- Onderbrekingsvermogen : 120 kA
- Normen : IEC 60 269
Specificaties
Artikelnummer
- PV141AaM
EAN
- 5415184508696
Model
- Ceramic fuse
Maat
- 14x51 mm
Voltage type
- AC/DC
Utilization category
- aM (switchgear protection)
With striker
- Nee
Type of fuse status indicator
- Other
Rated voltage DC
- 250
Breaking capacity at nominal voltage, AC
- 120
Breaking capacity at nominal voltage, DC
- 120
Rated voltage AC
- 690
Rated current
- 1
Power loss at rated current
- 0,23
