Cylindrische zekering 22x58mm 500Vac 63A gG
Artikelnr:
PV2263AgG
€ 5,13
excl. BTW
(
€ 6,21
Incl. BTW
)
excl. BTW
(
Incl. BTW
)
(
Incl. BTW
)
Omschrijving
- Small dimensions.
- High limiting and breaking capacity.
- Low power losses.
- The fuse-links do not contain harmful substances according to the RoHS Regulation (cadmium, lead and other).
- Utilization category gG for protection of lines, cables and other equipment against overload and short-circuit.
- Nominale spanning : 400 ÷ 690 V a.c.
- Onderbrekingsvermogen : 120 kA
- Normen : IEC 60 269
Specificaties
Artikelnummer
- PV2263AgG
EAN
- 5415184508856
Model
- Ceramic fuse
Maat
- 22x58 mm
Voltage type
- AC/DC
Utilization category
- gG (cable protection/equipment protection)
With striker
- Nee
Type of fuse status indicator
- Other
Rated voltage DC
- 250
Breaking capacity at nominal voltage, AC
- 120
Breaking capacity at nominal voltage, DC
- 120
Rated voltage AC
- 500
Rated current
- 63
Power loss at rated current
- 5,82
